- Size: 3.9*2.7*1.85m
- Place of Origin: Jinan
- Brand Name: GANGERCNC
- Model Number: SH-2030
- Weight: 2000.000 kg
Machine features:
1.Three axis adopts linear guide rail, running smoothly with high precision.
2.Adopt frequency conversion brushless spindle from domestic well-known brands with low noise,
and high cutting-force,which can ensure the long-term processing;
3.Whole steel structure machine body ensuring high stability.
4.Humanized control system shows advantages:continue engraving when broken point and
adjust processing time.
5.This is economical and practical machine type,suitable for perfect engraving and cutting on
plane stone product.
Applicable industry and material
Applicable industry:widely used in large stone panel engraving industry,craft processing
and building material industry.
Applicable material:stone,artificial marble,glass,brass,aluminum etc. Soft metal plate.
Technical parameters |
|
Model | SH-1325 |
X/Y/Z Axis reposition accuracy | 0.02mm |
X/Y/Z Axis working size | X=1300, Y=2500, Z =350mm |
Working table size | 1300*2500mm |
Feeding height | 400mm |
Max running speed | 30m/min |
Max working speed | 12m/min |
Working table | Aluminum profile with T slot with water-tank |
X/Y/Z Axis transmission | X/Y Axis Gear and rack ,Z Axis Ball screw |
Guide rail | Square guide rail |
Spindle power | Water-cooled 5.5kw |
Max spindle speed | 0-24000rpm |
Collet/Blade diameter | ER 25 2-16mm |
Driver motor | Stepper motor,imported servo motor optional |
Working voltage | AC380v/50Hz |
Control system | NCSTUDIO/ DSP |
Gross weight | 2.0t |
Remark: All machine models can be customized according to clients’ special requirement. | |
